Aune N5 EVO - Music Streamer

Aune N5 EVO is a sophisticated network-based music player and streamer, designed for audiophiles seeking high-performance sound reproduction in a compact format. This device combines modern streaming technology with reference-level sound quality, and is built on an architecture similar to a traditional CD player but focused on digital audio decoding. It uses a dedicated CPU solely for audio restoration, resulting in a clean and simple signal path without unnecessary interference.

• DAC and Processor: Equipped with ESS9039Q2M DAC chip, NXP Cortex-M7 processor, and Intel FPGA for precise signal processing. FIFO technology and dual internal PLL generators minimize jitter and ensure smooth, detailed sound reproduction.
• Support for High-Resolution Audio: Handles PCM up to 32-bit/768 kHz and DSD up to DSD512 for analog output. For digital outputs, it supports PCM up to 24-bit/192 kHz (coaxial/optical) and up to 32-bit/384 kHz/DSD256 (I2S). Local files include DSD, APE (up to 192 kHz/24-bit), FLAC (up to 384 kHz/32-bit), WAV, MP3, WMA, AAC, ALAC, AIFF, and CUE.
• Wireless Connectivity: Bluetooth 5.1 with Qualcomm QCC5125 module, supporting aptX HD and LDAC codecs for near lossless wireless transmission up to 990 kbps. Wi-Fi (2.4G) enables streaming from platforms such as AirPlay 2, Spotify, Tidal, Deezer, Qobuz, Amazon Music, and NetEase Cloud.
• Inputs and Outputs: Wi-Fi, Bluetooth, and 2× USB drives for local playback. Outputs include balanced XLR, unbalanced RCA (analog), I2S, coaxial (RCA), optical Toslink, and a BNC input for external 10 MHz clock for improved timing accuracy.
• User Interface: Display for volume, inputs, etc. Remote control. App support ("aune control" for iOS & Android).
• Accessories: Includes power cable, remote control, and user manual.

Maximize performance?

If you want to fully optimize the N5, it is recommended to run it together with Aune NC1 where you get both linear power supply and precise clock synchronization.

Specifications:

• Digital Performance: THD+N: -141.6 dB (24-bit/44.1 kHz), Jitter: 171.5 ps (24-bit/44.1 kHz).
• Analog Performance: SNR: 109 dB, THD+N: -107 to -109 dB (1 kHz, 24-bit/44.1 kHz), Frequency response: ±0.5 dB (20 Hz–20 kHz), Noisefloor: 2.5 μV.
• Power Supply: 9V DC, Consumption: 3W (standby), up to 5W (max).
• Other: Support for external clock (10 MHz), wireless interface (2.4G Bluetooth and Wi-Fi).
• Dimensions: 208 x 63 x 160 (W x H x D)
